2020 Specialized Shiv Sport Features
Pro Tip: Use our
Shiv Finder
to determine the proper Shiv size for you.
The Shiv was designed with one goal in mind—making you faster over the bike leg of your race. Of course, we wanted to do this without setting you back six months' rent. So, whether you're looking to go after your first triathlon or set a fresh PR, you can ride with the confidence that your Shiv is up to the task.
The Shiv Sport is built up with a mix of Shimano Tiagra and microSHIFT components, and it's been topped off with durable, smooth-rolling DT R460 wheels and a Sitero Comp saddle.
At a Glance
- A full FACT 10r carbon fiber frame was developed in our very own Win Tunnel, and it's not only been aerodynamically optimized for straight-line speed, but it also features airfoils that have been optimized to limit side force in crosswinds.
- A bike can only be as fast as its rider, which is why we developed the Control Tower fit system that let's you optimize your stack and reach numbers in order to find your most comfortable and powerful position for your desired length.
- The Fuselage Hydration System houses a water bladder inside of the frame, making it virtually invisible to the wind. And to go along with your water, the Fuelcell fits plenty of food and even has room for a flat kit. The best part of the Fuselage and Fuelcell combination is that, when packed correctly, it cleans up the frame and saves up to 75 seconds when compared to a taped-up system. For this model Shiv, the Fuelselage and Fuelcell are sold separately.
Component Specifications
| Frameset |
frame
|
| Suspension |
fork
|
| Brakes |
front brake
rear brake
|
| Drivetrain |
shift levers
front derailleur
rear derailleur
cassette
chain
crankset
bottom bracket
|
| Wheels & Tires |
front tire
rear tire
inner tubes
front wheel
rear wheel
|
| Cockpit |
stem
handlebars
saddle
seatpost
tape
|
2020 Specialized Shiv Sport
| Bike/Frame Size | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Stack | 495 mm | 514 mm | 540 mm | 565 mm | 590 mm |
| Reach | 365 mm | 385 mm | 405 mm | 425 mm | 445 mm |
| Chainstay Length | 395 mm | 395 mm | 395 mm | 395 mm | 395 mm |
| Wheelbase | 958 mm | 974 mm | 993 mm | 1016 mm | 1044 mm |
| Top Tube Length, Horizontal | 479 mm | 504 mm | 530 mm | 555 mm | 581 mm |
| Bike Standover Height | 752 mm | 772 mm | 797 mm | 822 mm | 847 mm |
| Seat Tube Length | 505 mm | 525 mm | 551 mm | 577 mm | 603 mm |
| Seat Tube Angle | 77° | 77° | 77° | 77° | 77° |
| Head Tube Length | 99 mm | 115 mm | 139 mm | 163 mm | 189 mm |
| Head Tube Angle | 70.25° | 71.5° | 72° | 72.5° | 72.5° |
| BB Height | 258 mm | 258 mm | 258 mm | 258 mm | 258 mm |
| BB Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Trail | 65 mm | 58 mm | 60 mm | 57 mm | 57 mm |
| Fork Length, Full | 367 mm | 367 mm | 367 mm | 367 mm | 367 mm |
| Fork Rake/Offset | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm |
| Front Center | 574 mm | 590 mm | 609 mm | 632 mm | 659 mm |
Component Geometry
| Component | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Crank Length | 165mm mm | 170mm mm | 172.5mm mm | 172.5mm mm | 175mm mm |
| Handlebar Width | 410mm mm | 410mm mm | 410mm mm | 410mm mm | 410mm mm |
| Stem Length | 90mm mm | 90mm mm | 90mm mm | 90mm mm | 90mm mm |
| Saddle Width | mm | mm | mm | mm | mm |
| Seatpost Length | 350mm mm | 350mm mm | 350mm mm | 350mm mm | 350mm mm |
