Specialized Fuse 29/6fattie Features
If you show us a trail rider that says they couldn't use more traction, we'll show a trail rider that's never ridden our Fuse. We like to call it the ultimate trail hardtail, and with a 27.5+ tire system, this becomes more than just talk. Its 27.5 x 3.0" tires put out more traction, more floatation, and better handling without sacrificing anything to efficiency on climbs. And to solidify itself as a sweet trail machine, this iteration of the Fuse places a focus on blending tough-as-nails durability with reliable performance. This meant spec'ing it with strong alloy rims, a bulletproof one-by drivetrain with plenty of hammering and climbing ability, and an SR Suntour fork with 120mm of travel. It has everything you need to ride harder and go faster, and nothing that you don't.
- The frame features an A1 Premium Aluminum construction that provides an ideal blend of efficiency and durability.
- An SR Suntour XCM32 6Fattie fork features stiff 32mm stanchions and up to 120mm of smooth travel.
- Shimano Deore shifting kit is precise and damn tough, so it can face down rock gardens and rough trails while still providing accurate and reliable shifting.
Component Specifications
| Frame | A1 Premium Aluminum W/ Smooth Welds, Zero Stack 44 Head Tube, Forged Post-mount 160mm Disc, 141mm Qr Dropout, Alloy Replaceable Derailleur Hanger |
| Seat Binder | Alloy, Bolt-type, 34.9mm |
| Fork | Sr Suntour Xcm32, 47mm Offset, 110x15mm Thru-axle, 120mm Of Travel |
| Shift Levers | Shimano Deore, 10-speed |
| Rear Derailleur | Shimano Deore, Shadow Plus, Gs Cage, 10-speed |
| Cassette | Shimano, 10spd, 11-42t |
| Chain | Kmc X10, 10-speed W/ Reusable Missing Link™ |
| Crankset | Stout, Forged Alloy, 76mm Bcd |
| Bottom Bracket | Square Taper, 73mm, Internal Bearings |
| Rims | Stout Trail 27.5, 38mm Internal Width, Disc-specific |
| Front Hub | Stout, Alloy, Sealed Cartridge Bearings, 15x110mm Thru-axle, 24h |
| Rear Hub | Stout, Alloy, Sealed Cartridge Bearings, 6-bolt Disc, 10-speed Freehub, Quick-release, 28h |
| Spokes | Stainless, 14g |
| Front Tire | Purgatory, Grid Casing, Gripton® Compound, 2bliss Ready, 27.5 X 3.0" |
| Rear Tire | Purgatory, Grid Casing, Gripton® Compound, 2bliss Ready, 27.5 X 3.0" |
| Inner Tubes | Presta, 40mm Valve |
| Front Brake | Tektro Auriga, Hydraulic Disc, 180mm |
| Rear Brake | Tektro Auriga, Hydraulic Disc, 160mm |
| Stem | Specialized, 3d-forged Alloy, 4-bolt, 7-degree Rise |
| Handlebars | Stout Riser, Double-butted Alloy, 9-degree Backsweep, 5-degree Upsweep, 15mm Rise, 750mm Width, 31.8mm |
| Grips | Specialized Sip Grip, Half-waffle, S/m: Regular Thickness, L/xl: Xl Thickness |
| Saddle | Body Geometry Henge Comp, Hollow Cr-mo Rails, 143mm |
| Seatpost | Transx Dropper, Tranzx Dropper, Internal Cable Routing, Remote Lever, 30.9mm, 120mm Travel |
Size Guide: Specialized Fuse 29/6fattie
