Specialized Epic Evo Pro Features
Trail-worthy; meet drool-worthy. Perfect, now that introductions are out of the way, let's do our best to try and grasp the fact that the Epic EVO Pro manages to channel the Epic's standard-setting pedaling efficiency while delivering jaw-dropping on-trail capability—and look darn good doing it.
While the Epic EVO sees a seemingly modest 20-millimeter increase in suspension travel up front over its Epic stablemate and just 10-millimeters out back, we've worked overtime to make sure it's been implemented in a way that'll have you saying 'Whoa!' as soon as you hit your first stretch of singletrack.
Meticulously engineered to retain as much of the Epic's standard-setting efficiency as possible, the EVO's new suspension kinematics work in concert with Rx XC Tune customized suspension front and rear to ensure you're able to make the absolute most out of every inch of travel on tap, while still offering increased anti-squat characteristics for improved pedaling efficiency.
With plenty of practice at staying ahead of the curve, the Epic EVO now lays claim to the most capable iteration of our Progressive XC Geometry ever to grace an Epic. It's also more versatile than ever thanks to a new flip chip-equipped rear end that allows riders to adjust headtube angle and bottom bracket height to easily customize Epic EVO's handling characteristics.
Dressed to impress, the Epic EVO Pro sports top-shelf Fox Factory suspension front and rear to keep things poised when the going gets rough, while the silky shifts and rock-solid performance of Shimano's 12-speed XTR group will never go out of style.
At a Glance
- Flip It To Rip It: Tune the ride of the Epic EVO’s FACT 11m carbon frame to match your preferred handling characteristics with flip-chip simplicity that allows riders to steepen the EVO’s headtube angle by half a degree while raising the bottom bracket height by six millimeters.
- Pairing the FOX FLOAT Step-Cast 34 Factory's lightweight chassis with the Fit4 damper's impressive control and on-the-fly compression adjustment makes for a fork with impressive performance both climbing and descending, making it a perfect match for the Epic EVO.
- Stuck in your search for braking bliss? Don't worry, Shimano's XTR M9120 brakes will see you on your way to braking nirvana with their Servo-Wave roller-cam levers and superlative stopping power coming from four ceramic pistons per caliper.
- 27 years of loving devotion—and countless engineering hours—from Shimano have certainly paid dividends for their legendary XTR groupset, breaking it's own performance benchmarks time and time again in it's wildly successful quest for the ultimate shifting experience.
- Descending from a long World Cup lineage, hand-built Roval Control Carbon wheels feature a modern 25-millimeter internal-width hookless rim, and maximize strength, ride quality, and durability while keeping weight to a minimum.
Component Specifications
| Frame | FACT 11m Full Carbon, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 110mm of travel |
| Seat Binder | Specialized Alloy, 34.9mm |
| Fork | FOX FLOAT Step-Cast 34 Factory, Fit4 damper, Kashima Coating, 15x110mm, 44mm offset, 120mm of travel |
| Rear Shock | FOX FLOAT DPS Factory, Rx XC Tune, EVOL Air sleeve, Kashima Coat, 3-position adjustment w/ Open Mode Adjustment, 190x40mm |
| Shift Levers | Shimano XTR M9100, 12-speed |
| Rear Derailleur | Shimano XTR M9100, 12-speed, Shadow Plus |
| Cassette | Shimano XTR M9100, 12-speed, 10-51t |
| Chain | Shimano XTR M9100, 12-speed w/ quick link |
| Crankset | Shimano XTR 9100, Hollowtech 2, 162 q-factor, 32T Chainring, SM: 170mm, M-XL: 175mm |
| Chain Rings | 32T |
| Bottom Bracket | Shimano, BB-MT800, Threaded |
| Rims | Roval Control Carbon, 25mm internal width, Zero bead hook, Tubeless ready, 28h |
| Front Hub | DT Swiss 350, 15x110mm spacing, 6-bolt, 28h |
| Rear Hub | DT Swiss 350, Star Ratchet, Shimano Microspline driver body, 12mm thru-axle, 148mm spacing, 28h |
| Spokes | DT Swiss Competition Race |
| Front Tire | Ground Control, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3" |
| Rear Tire | Fast Trak, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3" |
| Inner Tubes | Presta, 60mm valve |
| Front Brake | Shimano XTR M9120, 4-piston caliper, hydraulic disc, 180mm rotor |
| Rear Brake | Shimano XTR M9120, 4-piston caliper, hydraulic disc, 180mm rotor |
| Stem | Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise |
| Handlebars | S-Works Carbon XC Mini Rise, 6-degree upsweep, 8-degree backsweep, 10mm rise, 760mm, 31.8mm |
| Grips | Specialized Trail Grips |
| Saddle | Body Geometry Power Expert |
| Seatpost | Fox Factory Transfer, Kashima, 30.9mm, 125mm / 150mm travel |
Specialized Epic Evo Pro
| Bike/Frame Size | S | M | L | XL |
|---|---|---|---|---|
| Stack | 593 mm | 597 mm | 611 mm | 629 mm |
| Reach | 406 mm | 436 mm | 460 mm | 485 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1132 mm | 1164 mm | 1194 mm | 1227 mm |
| Bike Standover Height | 779 mm | 781 mm | 793 mm | 804 mm |
| Seat Tube Length | 400 mm | 430 mm | 470 mm | 520 mm |
| Seat Tube Angle | 74.8° | 74.5° | 74.5° | 74.5° |
| Top Tube Length, Horizontal | 567 mm | 602 mm | 629 mm | 659 mm |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 135 mm |
| Head Tube Angle | 66.5° | 66.5° | 66.5° | 66.5° |
| BB Height | 336 mm | 336 mm | 336 mm | 336 mm |
| BB Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Trail | 114 mm | 114 mm | 114 mm | 114 mm |
| Fork Length, Full | 530 mm | 530 mm | 530 mm | 530 mm |
| Fork Rake/Offset | 44 mm | 44 mm | 44 mm | 44 mm |
| Front Center | 697 mm | 729 mm | 759 mm | 792 mm |
