2022 Specialized S-Works Epic Hardtail Frameset

2022 Specialized S-Works Epic Hardtail Frameset

71322-0001

$3,000.00
$3,000.00 $3,000.00
Sold out
Color
Size
View full details

    2022 Specialized S-Works Epic Hardtail Frameset Features

    The S-Works Epic Hardtail is the lightest and most capable carbon hardtail frame ever created. Need we say more?

    While that does a great job of summing things up, if we’re being honest, we’re still a bit too proud to leave it at that. An impressive 140 grams lighter than the already

    ‘how’d they do that’ -light Epic Hardtail frame, the S-Works frame makes use of our FACT 12m carbon to cut a figure that’ll make any gram-counter swoon, while still offering riders enough capability and composure to wring out extra seconds on any section of course, not just the groomed bits.

    Working towards the lightest bike possible has long been the race within the race, but at what cost? The battle of the grams certainly hasn’t been without its casualties, with hardtail XC race bikes coming to stand for a harsh, twitchy ride at the expense of capability and versatility.

    But who said fatigue from fighting against your own bike makes you any faster? Instead, recognizing that the fastest bike is more than simply the lightest bike, we said out with the

    jarred-to-death tail ; the

    measure-your-posterior’s-sorrows-by-the-yard tail

    and in with the

    avant-garde tail . The ridiculously capable, mystifyingly comfortable, head-shakingly light and all-around fast, Epic Hardtail.

    Sure; we optimized every inch of the Epic Hardtail frame to achieve the lightest production hardtail frame in the world anyway, but we also prioritized our commitment to creating an Epic Hardtail that’s as capable as it is comfortable with aggressive singletrack-inspired geometry, increased tire clearance and a frame obsessively engineered for increased vertical compliance, all while creating a bike that lives and breathes the fundamentals of fast.

    At a Glance

    • Ridiculously capable and refreshingly compliant with a weight that'll make most road frames jealous, the FACT 12m carbon S-Works Epic Hardtail frame isn't just light, it's the lightest production hardtail frame ever produced.

    Product Specifications

    frame

    S-Works FACT 12m, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing,

    seatpost

    S-Works FACT carbon, 10mm offset, 30.9mm

    seat binder

    Specialized Alloy, 34.9mm, Titanium bolt

    category

    Mountain

    component geometry

    [{"COMPONENT_GEO_CODE":"12912786","COMPONENT_MEASUREMENT_DESC":"Seatpost Length","COMPONENT_GEO_UOM":"mm","COMPONENT_GEO_DISPLAY_ORDER":"105","SIZE_DESC":"M","GEO_SIZE_VALUE":"400","GEO_SIZE_DISPLAY_ORDER":"3"},{"COMPONENT_GEO_CODE":"12912786","COMPONENT_MEASUREMENT_DESC":"Seatpost Length","COMPONENT_GEO_UOM":"mm","COMPONENT_GEO_DISPLAY_ORDER":"105","SIZE_DESC":"L","GEO_SIZE_VALUE":"400","GEO_SIZE_DISPLAY_ORDER":"4"},{"COMPONENT_GEO_CODE":"12912786","COMPONENT_MEASUREMENT_DESC":"Seatpost Length","COMPONENT_GEO_UOM":"mm","COMPONENT_GEO_DISPLAY_ORDER":"105","SIZE_DESC":"XL","GEO_SIZE_VALUE":"400","GEO_SIZE_DISPLAY_ORDER":"5"},{"COMPONENT_GEO_CODE":"12912786","COMPONENT_MEASUREMENT_DESC":"Seatpost Length","COMPONENT_GEO_UOM":"mm","COMPONENT_GEO_DISPLAY_ORDER":"105","SIZE_DESC":"XS","GEO_SIZE_VALUE":"350","GEO_SIZE_DISPLAY_ORDER":"1"},{"COMPONENT_GEO_CODE":"12912786","COMPONENT_MEASUREMENT_DESC":"Seatpost Length","COMPONENT_GEO_UOM":"mm","COMPONENT_GEO_DISPLAY_ORDER":"105","SIZE_DESC":"S","GEO_SIZE_VALUE":"350","GEO_SIZE_DISPLAY_ORDER":"2"}]

    experience

    Cross Country

    frame geometry

    [{"GEO_SET_NAME":"EPIC HT Carbon (XC HT H1.1 H1.2)","GEO_SET_ID":"12972","MODEL_YEAR":"2022","Children":[{"GEO_MEASUREMENT_DESCRIPTION":"Head Tube Length","MEASUREMENT_GEO_CODE":"185156","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"2","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"95","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"95","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"95","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"110","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"125","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Fork Rake/Offset","MEASUREMENT_GEO_CODE":"185162","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"8","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"44","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"44","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"44","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"44","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"44","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Seat Tube Angle","MEASUREMENT_GEO_CODE":"185169","UOM":"degrees","GEO_MEASUREMENT_DISPLAY_ORDER":"15","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"74","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"74","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"74","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"74","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"74","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Reach","MEASUREMENT_GEO_CODE":"185155","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"1","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"385","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"405","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"430","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"455","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"480","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Head Tube Angle","MEASUREMENT_GEO_CODE":"185157","UOM":"degrees","GEO_MEASUREMENT_DISPLAY_ORDER":"3","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"68.5","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"68.5","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"68.5","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"68.5","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"68.5","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Seat Tube Length","MEASUREMENT_GEO_CODE":"185168","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"14","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"367","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"400","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"430","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"470","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"520","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"BB Height","MEASUREMENT_GEO_CODE":"185158","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"4","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"309","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"309","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"309","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"309","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"309","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Top Tube Length, Horizontal","MEASUREMENT_GEO_CODE":"185166","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"12","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"555","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"579","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"604","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"633","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"662","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Bike Standover Height","MEASUREMENT_GEO_CODE":"185167","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"13","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"732","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"762","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"792","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"816","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"847","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Stack","MEASUREMENT_GEO_CODE":"185154","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"0","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"594","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"608","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"608","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"622","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"636","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"BB Drop","MEASUREMENT_GEO_CODE":"185159","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"5","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"63","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"63","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"63","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"63","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"63","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Wheelbase","MEASUREMENT_GEO_CODE":"185165","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"11","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"1064","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"1092","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"1117","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"1148","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"1178","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Front Center","MEASUREMENT_GEO_CODE":"185163","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"9","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"643","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"670","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"695","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"725","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"755","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Chainstay Length","MEASUREMENT_GEO_CODE":"185164","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"10","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"430","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"430","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"430","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"430","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"430","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Trail","MEASUREMENT_GEO_CODE":"185160","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"6","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"101","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"101","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"101","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"101","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"101","GEO_DISPLAY_ORDER":"4"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Fork Length, Full","MEASUREMENT_GEO_CODE":"185161","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"7","Children":[{"FRAME_SIZE_DESC":"XS","GEO_VALUE":"486","GEO_DISPLAY_ORDER":"0"},{"FRAME_SIZE_DESC":"S","GEO_VALUE":"506","GEO_DISPLAY_ORDER":"1"},{"FRAME_SIZE_DESC":"M","GEO_VALUE":"506","GEO_DISPLAY_ORDER":"2"},{"FRAME_SIZE_DESC":"L","GEO_VALUE":"506","GEO_DISPLAY_ORDER":"3"},{"FRAME_SIZE_DESC":"XL","GEO_VALUE":"506","GEO_DISPLAY_ORDER":"4"}]}]}]

    gender

    Men|Women

    group

    Framesets

    line

    BIKES

    material

    Carbon

    model level

    S-Works

    model year

    2022

    product family

    Epic Hardtail

    shifting

    Mechanical

    suspension

    Rigid

    wheel size

    29"

    base color

    Black

    color

    Gloss Chameleon Fluid / Satin Black

    size

    XS

    2022 Specialized S-Works Epic Hardtail Frameset

    Bike/Frame Size XS S M L XL
    Stack 594 mm 608 mm 608 mm 622 mm 636 mm
    Reach 385 mm 405 mm 430 mm 455 mm 480 mm
    Chainstay Length 430 mm 430 mm 430 mm 430 mm 430 mm
    Wheelbase 1064 mm 1092 mm 1117 mm 1148 mm 1178 mm
    Top Tube Length, Horizontal 555 mm 579 mm 604 mm 633 mm 662 mm
    Bike Standover Height 732 mm 762 mm 792 mm 816 mm 847 mm
    Seat Tube Length 367 mm 400 mm 430 mm 470 mm 520 mm
    Seat Tube Angle 74° 74° 74° 74° 74°
    Head Tube Length 95 mm 95 mm 95 mm 110 mm 125 mm
    Head Tube Angle 68.5° 68.5° 68.5° 68.5° 68.5°
    BB Height 309 mm 309 mm 309 mm 309 mm 309 mm
    BB Drop 63 mm 63 mm 63 mm 63 mm 63 mm
    Trail 101 mm 101 mm 101 mm 101 mm 101 mm
    Fork Length, Full 486 mm 506 mm 506 mm 506 mm 506 mm
    Fork Rake/Offset 44 mm 44 mm 44 mm 44 mm 44 mm
    Front Center 643 mm 670 mm 695 mm 725 mm 755 mm

    Component Geometry

    Component XS S M L XL
    Seatpost Length 350 mm 350 mm 400 mm 400 mm 400 mm
