Specialized Epic Hardtail Sw Features
What do you call a hardtail race bike so light it can put most road bikes to shame? Well, we suppose you could call it a hardly-there-tail, but it actually goes by the name of the S-Works Epic Hardtail. Even while barely registering on the scale, we’ve loaded it with enough capability to do quite a number on the trail. Welcome to having your cake and eating it too—S-Works style. Working towards the lightest bike possible has long been the race within the race, but at what cost? The battle of the grams certainly hasn’t been without its casualties, with hardtail XC race bikes coming to stand for a harsh, twitchy ride at the expense of capability and versatility. But who said fatigue from fighting against your own bike makes you any faster? Instead, recognizing that the fastest bike is more than simply the lightest bike, we said out with the
jarred-to-death tail ; the
measure-your-posterior’s-sorrows-by-the-yard tail
and in with the
avant-garde tail . The ridiculously capable, mystifyingly comfortable, head-shakingly light and all-around fast, Epic Hardtail. Sure, we optimized every inch of the Epic Hardtail frame to achieve the lightest production hardtail frame in the world anyway, but we also prioritized our commitment to creating an Epic Hardtail that’s as capable as it is comfortable with aggressive singletrack-inspired geometry, increased tire clearance and a frame obsessively engineered for increased vertical compliance, all while creating a bike that lives and breathes the fundamentals of fast. Such an unbeleivably lightweight yet impressively capable frame deserves a build to match and the S-Works Epic Hardtail certainly doesn't disappoint. SRAM's Eagle XX1 AXS electronic groupset and the featherweight Roval Control SL wheelset lead the charge in dropping some serious grams while seriously ratcheting up performance.
At a Glance
- Ridiculously capable and refreshingly compliant with a weight that'll make most road frames jealous, the FACT 12m carbon S-Works Epic Hardtail frame isn't just light, it's the lightest production hardtail frame ever produced.
- Pairing 100 millimeters of the most efficent travel on earth with RockShox's svelte-yet-stiff SID SL Ultimate chassis, the RockShox SID SL Ultimate BRAIN fork serves as the pinnacle of XC-race supsension perfection.
- The pinnacle of drivetrain performance, SRAM's XX1 Eagle AXS combines next-gen wireless technology, incredibly accurate shift performance and game-changing versatility to drastically redefine the riding experience.
- Weighing a remarkable 1240 grams, the Roval Control SL wheelset not only increases strength and reduces weight, but also features a new 29-millimeter-wide internal width rim profile that improves pinch-flat resistance by 22-percent.
Component Specifications
| Frame | S-Works FACT 12m, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, |
| Seat Binder | Specialized Alloy, 34.9mm, Titanium bolt |
| Fork | RockShox SID SL ULTIMATE BRAIN, Top-Adjust Brain damper, Debon Air, 15x110mm, 44mm offset, 100mm Travel |
| Shift Levers | SRAM Eagle AXS Rocker Paddle |
| Rear Derailleur | SRAM XX1 Eagle AXS |
| Cassette | Sram XG-1299, 12-Speed, 10-52t |
| Chain | SRAM XX1 Eagle |
| Crankset | Quarq XX1 Powermeter, DUB, 170/175mm, 34t |
| Chain Rings | 34T |
| Bottom Bracket | SRAM DUB, BSA 73mm, Threaded |
| Rims | Roval Control SL, Carbon offset design, 29mm internal width, 4mm hook width, Tubeless ready, 24h |
| Front Hub | Roval Control SL, DT Swiss Internals, Ceramic Bearings, 6-bolt, 15mm thru-axle, 110mm spacing, Torque caps, 24h straight pull t-head |
| Rear Hub | Roval Control SL, DT Swiss 180 Internals, DT Swiss Ratchet EXP, Ceramic bearings, 12mm thru-axle, 148mm spacing, 24h straight-pull t-head |
| Spokes | DT Swiss Aerolite |
| Front Tire | Specialized Fast Trak, Control Casing, T5 Compound, 29x2.35 |
| Rear Tire | Specialized Renegade, Control Casing, T5 Compound, 29x2.35 |
| Inner Tubes | Turbo Tube w/Talc 40mm PV 29x1.75-2.4 |
| Front Brake | SRAM Level Ultimate, 2-piston caliper, hydraulic disc |
| Rear Brake | SRAM Level Ultimate, 2-piston caliper, hydraulic disc |
| Stem | S-Works SL, alloy, titanium bolts, 6-degree |
| Handlebars | S-Works Carbon XC Mini Rise, 6-degree upsweep, 8-degree backsweep, 10mm rise, 760mm, 31.8mm |
| Grips | Specialized Trail Grips |
| Saddle | Body Geometry S-Works Power, carbon fiber rails, carbon fiber base |
| Seatpost | S-Works FACT carbon, 10mm setback, 30.9mm |
Specialized Epic Hardtail Sw
| Bike/Frame Size | S | M | L | XL |
|---|---|---|---|---|
| Stack | 608 mm | 608 mm | 622 mm | 636 mm |
| Reach | 405 mm | 430 mm | 455 mm | 480 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1092 mm | 1117 mm | 1148 mm | 1178 mm |
| Top Tube Length, Horizontal | 579 mm | 604 mm | 633 mm | 662 mm |
| Bike Standover Height | 762 mm | 792 mm | 816 mm | 847 mm |
| Seat Tube Length | 400 mm | 430 mm | 470 mm | 520 mm |
| Seat Tube Angle | 74° | 74° | 74° | 74° |
| Head Tube Length | 95 mm | 95 mm | 110 mm | 125 mm |
| Head Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° |
| BB Height | 309 mm | 309 mm | 309 mm | 309 mm |
| BB Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Trail | 101 mm | 101 mm | 101 mm | 101 mm |
| Fork Length, Full | 506 mm | 506 mm | 506 mm | 506 mm |
| Fork Rake/Offset | 44 mm | 44 mm | 44 mm | 44 mm |
| Front Center | 670 mm | 695 mm | 725 mm | 755 mm |
