Specialized Enduro Sw Features
This is the bike that defines the very genre that bears its name—the S-Works Enduro climbs with utmost efficiency yet stays calm on even the gnarliest descents. It features a bomber, yet lightweight carbon frame that blissfully tackles the kind of terrain that chews up and spits out lesser bikes.
And with SRAM's XX1 Eagle AXS drivetrain and Code RSC four-piston disc brakes, FOX's latest Factory suspension, and top-of-the-line everything else, it's absolutely dressed to kill. Let the drooling begin.
At a Glance
- INCREDIBLY CAPABLE — If the Enduro looks like its sibling, the Demo, it's because they share plenty of downhill DNA. A more-rearward axle path reduces wheel hang-up on big impacts. A low- and forward-positioned shock keeps it planted and confident-feeling at high speeds. And balanced chassis stiffness helps the front-end steer precisely and keeps the rear-end tracking like it’s on rails. Add it all up and you have a bike that laughs in the face of the steepest, rockiest trails.
- ASTONISHINGLY FAST—UP AND DOWN THE TRAIL — Stomp on the pedals and the new Enduro accelerates far quicker than you'd expect possible from a downhill bruiser. To start, we increased anti-squat, so the suspension better-resists pedal bob. Then, to further its efficiency, we re-directed the angle of the chainstay and upper shock linkages for a much more efficient design. The end result? Less bobbing, more speed.
- FAST STARTS WITH FIT — Fast and fit aren't mutually exclusive, which is why the progressive geometry of the Enduro has been designed for going up and down. To start, seat tubes and stack heights don’t grow massively between sizes, meaning you can now pick a frame size based on both your height and your riding style. Pair this new sizing style with a slacker head angle, longer reach, and steeper seat tube across the line, and you’re left with a quicker and more capable steed, no matter the size.
Component Specifications
| Frame | FACT 11m carbon chassis and rear-end, S-Sizing Enduro Race Geometry, SWAT™ Door integration, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 170mm of travel |
| Seat Binder | Alloy, 38.6 |
| Fork | FOX FLOAT 38 Factory, GRIP2 damper, Kashima Coating, 15x110mm, 44mm offset, 170mm of travel |
| Rear Shock | FOX FLOAT X2 Factory, Rx Trail Tune, 2-position adjustment, high and low speed rebound and compression adjust, Trunnion mount, 205x60mm |
| Shift Levers | SRAM XX1 Eagle AXS |
| Rear Derailleur | SRAM XX1 Eagle AXS |
| Cassette | Sram XG-1299, 12-Speed, 10-52t |
| Chain | SRAM XX1 Eagle |
| Crankset | SRAM X01 Eagle, DUB, 170mm |
| Chain Rings | 30T |
| Bottom Bracket | SRAM DUB, BSA 73mm, Threaded |
| Rims | Roval Traverse SL 29, hookless carbon, 30mm inner width, 2Bliss Ready, hand-built, 28h |
| Front Hub | Roval Traverse SL, sealed cartridge bearings, 15mm thru-axle, 110mm spacing |
| Rear Hub | Roval Traverse SL, DT Swiss Star Ratchet, 54t engagement, SRAM XD driver body, 12mm thru-axle, 148mm spacing |
| Spokes | DT Competition Race |
| Front Tire | Butcher, GRID TRAIL casing, GRIPTON® compound, 29x2.3" |
| Rear Tire | Butcher, GRID TRAIL casing, GRIPTON® compound, 29x2.3" |
| Inner Tubes | Standard, Presta valve |
| Front Brake | SRAM Code RSC, 4-piston caliper, hydraulic disc, 220mm |
| Rear Brake | SRAM Code RSC, 4-piston caliper, hydraulic disc, 200mm |
| Stem | Deity, 35.0mm |
| Handlebars | Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm, 35.0mm |
| Grips | Deity, Knuckleduster, Black |
| Saddle | Bridge, 155/143mm, Hollow Ti-rails |
| Seatpost | RockShox Reverb AXS, 30.9, 1X remote, (S2/S3: 150mm, S4/S5:170mm) |
Specialized Enduro Sw
| Bike/Frame Size | S2 | S3 | S4 | S5 |
|---|---|---|---|---|
| Stack (low BB) | 616 mm | 620 mm | 629 mm | 638 mm |
| Reach (low BB) | 437 mm | 464 mm | 487 mm | 511 mm |
| Fork Length (full) | 581 mm | 581 mm | 581 mm | 581 mm |
| Fork Rake/Offset | 46 mm | 46 mm | 46 mm | 46 mm |
| Front-Center (low BB) | 777 mm | 806 mm | 833 mm | 862 mm |
| Chain-Stay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1217 mm | 1246 mm | 1274 mm | 1302 mm |
| Seat-Tube Length | 400 mm | 420 mm | 440 mm | 465 mm |
| Seat-Tube Angle | 76° | 76° | 76° | 76° |
| Top Tube Length (Horizontal) | 591 mm | 619 mm | 644 mm | 670 mm |
| Head-Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Head-Tube Angle (low BB) | 63.9° | 63.9° | 63.9° | 63.9° |
| Head-Tube Angle | 64.3 mm | 64.3 mm | 64.3 mm | 64.3 mm |
| B-B Height (low BB) | 347 mm | 347 mm | 347 mm | 347 mm |
| B-B Height | 354 mm | 354 mm | 354 mm | 354 mm |
| B-B Drop (low BB) | 28 mm | 28 mm | 28 mm | 28 mm |
| B-B Drop | 21 mm | 21 mm | 21 mm | 21 mm |
| Trail (low BB) | 132 mm | 132 mm | 132 mm | 132 mm |
Size Guide: Specialized Enduro Sw
