2027 Specialized S-Works Diverge 4 - SRAM RED XPLR

2027 Specialized S-Works Diverge 4 - SRAM RED XPLR

95427-0056

$12,499.99
$12,499.99 $12,499.99
New

Color
Size
View full details

    2027 Specialized S-Works Diverge 4 - SRAM RED XPLR Features

    Adventure approved & tuned for long-distance racing. The S-Works Diverge 4 is made for full-gas weekend rides and off-grid epics. With internal cable routing, Future Shock 3.3 suspension, massive tire clearance, and the biggest internal storage in gravel, the best gravel adventure bike in the world just got better. Chase adventure on the smoothest, most confident gravel bike ever.

    At a Glance

    • Use - Gravel Adventure
    • Frameset - FACT 12r Carbon
    • Suspension - Future Shock 3.3
    • Drivetrain/Wheels - SRAM RED XPLR/Roval Terra CLX III
    • Storage - SWAT 4.0
    • Weight - 8.2 kg

    Component Specifications

    Frameset
    frame
    Specialized Diverge FACT 12r carbon, SWAT™ Door integration, Future Shock suspension with integrated cable routing, threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout
    seat binder
    Specialized Alloy, 30.8mm
    Suspension
    fork
    Future Shock 3.3 w/ Smooth Boot, FACT 12r Carbon 12x100mm, thru-axle, flat-mount disc
    Brakes
    front brake
    SRAM RED E1, hydraulic disc
    rear brake
    SRAM RED E1, hydraulic disc
    Drivetrain
    shift levers
    SRAM RED AXS E1, hydraulic disc
    rear derailleur
    SRAM RED AXS XPLR E1, 13-speed
    cassette
    SRAM RED XPLR E1, 13-speed, 10-46t
    chain
    SRAM RED E1
    crankset
    SRAM RED E1 XPLR, DUB Wide, 40t, Quarq Power Meter
    bottom bracket
    Ceramic Speed BB Alpha, BSA DUB
    Wheels & Tires
    front tire
    Tracer TLR All Terrain Gravel Tire, 700x50c, Tubeless Ready
    rear tire
    Tracer TLR All Terrain Gravel Tire, 700x50c, Tubeless Ready
    inner tubes
    700x32-50mm, 40mm Presta valve
    front wheel
    Roval Terra CLX III, Tubeless, 27mm internal width carbon rim, 25.5 mm depth, 4.9mm bead hook width, Roval LF18-F hub, 21h, Roval by ARRIS Composite Straight Pull Spokes (Ti end fittings)
    rear wheel
    Roval Terra CLX III, Tubeless, 27mm internal width carbon rim, 25.5 mm depth, 4.9mm bead hook width, Roval LF19-R hub, 24h, Roval by ARRIS Composite Straight Pull Spokes (Ti end fittings)
    Cockpit
    handlebars
    Roval Terra Cockpit, Integrated Bar/Stem
    saddle
    S-Works Power with Mirror
    seatpost
    Roval Terra Carbon Seat Post, 20mm Offset
    tape
    Supacaz Super Sticky Kush
    Accessories
    swat
    SWAT 4.1 internal downtube storage

    2027 Specialized S-Works Diverge 4 - SRAM RED XPLR

    Bike/Frame Size 49 52 54 56 58 61
    Stack 563 mm 578 mm 592 mm 610 mm 634 mm 659 mm
    Reach 365 mm 374 mm 387 mm 400 mm 412 mm 425 mm
    Chainstay Length 430 mm 430 mm 430 mm 430 mm 430 mm 430 mm
    Wheelbase 1019 mm 1031 mm 1041 mm 1060 mm 1081 mm 1102 mm
    Top Tube Length, Horizontal 521 mm 537 mm 556 mm 575 mm 593 mm 613 mm
    Bike Standover Height 700 mm 725 mm 754 mm 779 mm 805 mm 832 mm
    Seat Tube Length 400 mm 430 mm 470 mm 500 mm 530 mm 560 mm
    Seat Tube Angle 74.5° 74° 74° 74° 74° 74°
    Head Tube Length 90 mm 104 mm 116 mm 135 mm 161 mm 187 mm
    Head Tube Angle 70° 70.5° 71° 71° 71° 71°
    BB Drop 85 mm 85 mm 85 mm 85 mm 85 mm 85 mm
    Trail 72 mm 68 mm 65 mm 65 mm 65 mm 65 mm
    Fork Length, Full 391 mm 391 mm 391 mm 391 mm 391 mm 391 mm
    Fork Rake/Offset 55 mm 55 mm 55 mm 55 mm 55 mm 55 mm
    Front Center 604 mm 613 mm 626 mm 645 mm 665 mm 686 mm

    Component Geometry

    Component 49 52 54 56 58 61
    Crank Length 165 mm 170 mm 172.5 mm 172.5 mm 175 mm 175 mm
    Handlebar Width 380 mm 380 mm 400 mm 420 mm 420 mm 420 mm
    Stem Length 75 mm 90 mm 90 mm 90 mm 90 mm 90 mm
    Saddle Width 155 mm 155 mm 143 mm 143 mm 143 mm 143 mm
    Seatpost Length 330 mm 330 mm 380 mm 380 mm 380 mm 380 mm

    Size Guide: 2027 Specialized S-Works Diverge 4 - SRAM RED XPLR

    Size guide for 2027 Specialized S-Works Diverge 4 - SRAM RED XPLR
