- InSet head tube interface (upper cup)
- head tube ID (tolerances): 44.00mm (+0.00, -0.05)
- maximum press fit: 0.05mm
- head tube ream depth: 10mm
- fork crown seat OD: 30.1mm
- stack height: 8.46mm
- InSet head tube interface (lower cup)
- head tube ID (tolerances): 44.00mm (+0.00, -0.05)
- maximum press fit: 0.05mm
- head tube ream depth: 10mm
- fork crown seat OD: 30.1mm
- stack height: 4.24mm
- Stem cap screw torque
- 68 - 170 N.cm (6-15in.lbs)
Since 1976 Chris King has been supplying cyclists with the best made, most reliable headsets you can buy. With proper installation and maintenance you can expect to enhoy the many years of the legendary quality and performance built into each and every component made.
