SPECIALIZED

2023 Specialized P.4 Frame

2023 Specialized P.4 Frame

71923-5027

$399.99
$699.99 $399.99
Sale
Color
Size
View full details

    2023 Specialized P.4 Frame Features

    This totally redesigned P.Series frame gives riders of all sizes a jumping off point to a life on bikes. The lightweight, but tough alloy frame is designed to take all the hits and keep rolling—across all frame sizes. Our approach to these robust bikes centers around delivering a simple, high-quality platform that's versatile for all riders, and packs in category-first features that make a difference to the rider.

    SLEEK SIMPLICITY — For the rider focusing on progression, eliminating every other variable is paramount. The durable lightweight alloy frame of the P.Series stands up to the tough demands of a modern DJ rig and accepts internally routed cables.

    SIZED FOR ALL — Frames available in dedicated 20”; 24”; and 26” configurations as well as the P.4 that can run both 26” and 27.5” (P.4 is spec’d with 27.5”).

    REIMAGINE YOUR RIDE — P.Series frames are dropper ready, derailleur compatible, and use adjustable dropouts.

    TOUGH TECH — Boost spacing in the rear, a tapered headtube, and threaded bottom-bracket make P.Series stiff and easy to maintain.

    At a Glance

    • Specialized P.4, A1 Premium Alloy, 27.5"; fully-butted tubing, dropper post compatible and 26" wheel compatible.

    Product Specifications

    frame

    Specialized P.4, A1 Premium Alloy, 27.5", Fully Butted Tubing, Tapered Head Tube, BSA 73mm BB Shell, 12x148TA Sliding Dropouts, Single Speed or Geared Compatible, 52mm CL, Internal cable routing, 30.9 Seat Tube, Dropper Post Compatible, 26" Wheel Compatible

    seat binder

    Alloy, single-bolt, 34.9mm

    category

    Mountain

    component geometry

    []

    experience

    Bmx / Dirt Jump

    frame geometry

    [{"GEO_SET_NAME":"P.4","GEO_SET_ID":"14415","MODEL_YEAR":"2023","Children":[{"GEO_MEASUREMENT_DESCRIPTION":"Wheel Size","MEASUREMENT_GEO_CODE":"110098","UOM":"inch","GEO_MEASUREMENT_DISPLAY_ORDER":"0","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"27.5","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Chain-Stay Length","MEASUREMENT_GEO_CODE":"143687","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"11","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"385","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Wheelbase","MEASUREMENT_GEO_CODE":"185165","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"12","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"1094","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Top-Tube Length (horizontal)","MEASUREMENT_GEO_CODE":"178222","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"13","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"636","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Bike Stand-Over Height","MEASUREMENT_GEO_CODE":"173619","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"14","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"697","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Seat-Tube Length","MEASUREMENT_GEO_CODE":"178224","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"15","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"350","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Seat-Tube Angle","MEASUREMENT_GEO_CODE":"139159","UOM":"degrees","GEO_MEASUREMENT_DISPLAY_ORDER":"16","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"72","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Fork Rake/Offset","MEASUREMENT_GEO_CODE":"185162","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"9","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"44","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Front-Center","MEASUREMENT_GEO_CODE":"145431","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"10","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"711","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Stack","MEASUREMENT_GEO_CODE":"185154","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"1","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"588","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Reach","MEASUREMENT_GEO_CODE":"185155","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"2","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"445","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Head-Tube Length","MEASUREMENT_GEO_CODE":"140152","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"3","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"120","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Head-Tube Angle","MEASUREMENT_GEO_CODE":"143686","UOM":"degrees","GEO_MEASUREMENT_DISPLAY_ORDER":"4","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"68.5","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"B-B Height","MEASUREMENT_GEO_CODE":"171029","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"5","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"318","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"B-B Drop","MEASUREMENT_GEO_CODE":"151451","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"6","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"34","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Trail","MEASUREMENT_GEO_CODE":"185160","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"7","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"91","GEO_DISPLAY_ORDER":"0"}]},{"GEO_MEASUREMENT_DESCRIPTION":"Fork Length (full)","MEASUREMENT_GEO_CODE":"178217","UOM":"mm","GEO_MEASUREMENT_DISPLAY_ORDER":"8","Children":[{"FRAME_SIZE_DESC":"P4","GEO_VALUE":"492","GEO_DISPLAY_ORDER":"0"}]}]}]

    group

    Framesets

    line

    BIKES

    material

    Aluminum

    model level

    Base

    model year

    2023

    product family

    P. Series

    shifting

    Mechanical

    suspension

    Rigid

    wheel size

    27.5"

    base color

    Green

    color

    Satin Rusted Red / White Sage

    size

    27.5"

    2023 Specialized P.4 Frame

    Bike/Frame Size P4
    Wheel Size 27.5 inch
    Stack 588 mm
    Front-Center 711 mm
    Chain-Stay Length 385 mm
    Wheelbase 1094 mm
    Top-Tube Length (horizontal) 636 mm
    Bike Stand-Over Height 697 mm
    Seat-Tube Length 350 mm
    Seat-Tube Angle 72°
    Reach 445 mm
    Head-Tube Length 120 mm
    Head-Tube Angle 68.5°
    B-B Height 318 mm
    B-B Drop 34 mm
    Trail 91 mm
    Fork Length (full) 492 mm
    Fork Rake/Offset 44 mm

    Size Guide: 2023 Specialized P.4 Frame

    Size guide for 2023 Specialized P.4 Frame
